Spezifikationen
The technical details below will help you find the right solution for your needs.
| MODEL |
2300 W MARINE SERIES |
3400W MARINE SERIES |
4500W MARINE SERIES |
| OPERATING MODE |
ELECTRICAL |
ELECTRICAL |
ELECTRICAL |
| COLOR |
BLACK | WHITE |
BLACK | WHITE |
BLACK | WHITE |
| WEIGHT |
8kg |
10kg |
15kg |
| HEATING AREA |
6 m² |
10 m² |
12 m²
|
| RATED CURRENT * |
220-220V/9.6A |
220-240V/14.2A |
220-240V/18.8A |
| MINIMUM GROUND CLEARANCE |
Wall 1.8 m
Ceiling 2.4m |
Wall 1.8 m
Ceiling 2.4 m |
Wall 1.8 m
Ceiling 2.4 m |
| GUARANTEE |
5-year spare parts warranty (The 5-year warranty applies only to land-based applications and does not cover marine installations) |
| CONTROL OPTIONS |
2300 W MARINE SERIES |
3400W MARINE SERIES |
4500W MARINE SERIES |
| AFFINITY ON/OFF |
✓ |
✓ |
✓ |
| AFFINITY DIMMER |
✓ |
✓ |
✓ |
*Available in different voltages: 220/240 V.
**Independent control of up to six heating zones with an unlimited number of heaters per zone via a single remote control. Dimmer control required. Control works within 30 m.
*Please visit Bromic Controls for more information.
Downloads
Installation
Installation must be performed by a licensed and authorized technician in accordance with local building codes. Please note our clearance requirements and consult the installation manual for further details.
Downloads
BIM- und CAD-Dateien
Um BIM- und CAD-Dateien herunterzuladen, füllen Sie das folgende Formular aus:
Häufig gestellte Fragen
Werden die Platinum-Electric-Marine-Heizungen mit einem Steuergerät geliefert?
No, the controllers can be purchased as additional accessories.
Kann ich die Platinum-Electric-Heizung selbst installieren?
No, the heater must be installed by a licensed technician.
Was ist Strahlungswärme?
Radiant heat works like the sun. Instead of warming the air around you, it warms people and objects. This makes radiant heat a more effective outdoor heating source because it’s less susceptible to wind.
Sind die Heizgeräte wasserdicht?
Our Platinum Electric marine heaters are constructed from high-quality 314 stainless steel and are IPX5 rated, meaning they are waterproof (low-pressure water jets). However, Bromic recommends installing them under a cover and avoiding direct exposure to rain and salt spray to maintain their aesthetic appeal.
Welche Befestigungsmöglichkeiten gibt es?
The heaters can be mounted either on a wall, on a pole, or in the ceiling. Each heater comes with a 20 cm mounting pole. Installation kits and longer poles for high ceilings can be ordered separately. Please refer to our instruction manual or contact our friendly design team to find out which installation and height is right for you.
